DualPath: Optimizing GPU Utilization for Agentic LLM Inference

Introduction

DualPath is an inference system developed by DeepSeek-AI that significantly improves GPU utilization for agentic Large Language Model (LLM) inference. It addresses the storage bandwidth bottleneck, enabling more efficient and cost-effective execution of complex, multi-turn AI workloads.

Configuration Checklist

Element	Version / Link
Language / Runtime	Not explicitly stated for DualPath implementation; ollama for demonstration.
Main library	DualPath (an inference system, not a traditional library for direct end-user integration).
Required APIs	Lambda GPU Cloud (for hosting powerful NVIDIA GPUs), ollama (for local LLM execution).
Keys / credentials needed	Lambda GPU Cloud account/API keys for cloud inference. No specific keys for ollama local execution.

Step-by-Step Guide

Step 1 — Understand the Storage Bandwidth Bottleneck

Traditional agentic LLM inference systems often suffer from inefficient GPU utilization because the process of reading data (prefill) from persistent storage (KV Cache) becomes a bottleneck. GPUs spend more time waiting for data than actively computing, leading to underutilization of expensive hardware.

# The video demonstrates running a DeepSeek AI model via Ollama.
# This command initiates the DeepSeek R1 model with 671 billion parameters.
# [Editor's note: Ensure Ollama is installed and the deepseek-r1:671b model is downloaded.]
ollama run deepseek-r1:671b

Step 2 — Implement DualPath for Efficient Data Flow

DualPath addresses this by introducing a 'spare read path' that leverages often-idle 'decode machines' to assist with 'prefill' tasks. Instead of all data flowing through a single, congested path to the 'prefill machines', the 'decode machines' are utilized to pre-process and cache data, effectively widening the 'straw' for information flow.

Step 3 — Prioritize Thinking Traffic with Intelligent Control

To prevent the new 'spare read path' from creating new bottlenecks, DualPath implements a traffic control mechanism. This system prioritizes 'thinking traffic' (the actual computation by the LLM) over 'memory traffic' (data loading for the KV Cache) on shared high-speed data roads. This ensures that the most critical operations for inference speed are not hampered by data transfer.

Comparison Tables

GPU Utilization Comparison

Approach	GPU Utilization	Description
Existing Bottleneck	~40%	GPUs are underutilized due to storage bandwidth limitations, leading to slow inference.
DualPath (Optimized)	~80%	Significantly improved utilization by leveraging idle decode machines for prefill tasks and intelligent traffic control.

Offline Inference Performance (JCT in seconds)

Note: Data extracted from Figure 7 of the referenced paper, showing Job Completion Time (JCT) for various agent configurations and context lengths. Lower JCT is better.

Max Agent Len	Number of Agents	Ours(oracle)	Ours	Ours(basic)	SGL(MC)
32k	512	~250	~300	~400	~1000
32k	1024	~500	~600	~800	~2000
32k	2048	~1000	~1200	~1600	~3000
32k	4096	~1500	~2000	~2500	~3500
48k	512	~500	~600	~800	~2000
48k	1024	~1000	~1200	~1600	~4000
48k	2048	~2000	~2500	~3000	~6000
48k	4096	~3000	~4000	~5000	~7000
64k	512	~1000	~1200	~1600	~4000
64k	1024	~2000	~2500	~3000	~8000
64k	2048	~4000	~5000	~6000	~12000
64k	4096	~6000	~8000	~10000	~14000

⚠️ Common Mistakes & Pitfalls

1. Assuming more GPUs automatically means faster inference: Simply adding more compute power (GPUs) does not guarantee proportional speed improvements if the data pipeline is bottlenecked. The fix is to optimize data flow and utilization before scaling hardware.
2. Inefficient data transfer between memory and compute: Information trickling in through a
